180W Portable Charger Aki 12/24V Mobil Dan Motor Dengan Intelligent Chip Charger Aki Mobil Lead Acid Smart Battery Charger 6-105AH MF-2B Smart Battery Charger Mobil Automatic Smart Intelligent Chip Kering Dan Basah Lead Acid Battery Charger Auto Cut Off

Charging time reference Battery（AH） Charging time（H） Battery（AH） Charging time（H） 3AH 0.5 6AH 1-2 9AH 1-3 36AH 7-8 45AH 7-10 60AH 9-14 80AH 10-15 105AH 　　 15-22 120AH 19-25 150AH 　 20-28 The product is suitable for It's compatible with all kinds of 12V /24V lead-acid battery, water battery, maintenance-free battery, dry battery charging. etc. (VELA BATTERY ,GEL BATTERY,OPZN BATTERY） And 12.6V lithum battery apply Cars, SUVs, motorcycles, electric vehicles, small trucks, tractors and other types of vehicles characteristic 1.12v/24v universal automatic identification 2. Compatible with 12.6V polymer lithium battery 3. Full charge automatically stops output current 4. Digital display: current, voltage, power and charging state in different stages 5. The current can be adjusted manually, automatic and manual charging mode, more reliable and safe Specifications Model：MF-2b / WLSH-20b Input voltage：110V ~ 250V Power：180W Output voltage：12V / 24V Frequency：50-60 Hz Working current：12v-10a/24v-7a working temperature：- 30 ℃ to + 50 ℃ Parameter Brand： LUNDA Model：XW-20B Item Weight：0.8kg Product Dimensions：17513860mm Cover Included：Battery charger and maintainer Alligator clips Amperage：12V-10A(max) 24V-7A(max) Voltage Identification:12V Peak (8-14.5V)；24V Peak (18-29V) Power:180W Battery Type: lead-acid battery, water battery, maintenance-free battery, dry battery charging. etc. (VELA BATTERY ,GEL BATTERY,OPZN BATTERY ) VI. Opladen operatie Please select "Automatic "repair "Automatic " repair allows you to connect the charger to your battery (either in or out of the vehicle) and forget about it until you are ready to put the battery to work. Like all Battery chargers, once the battery has reached a 100% charge the "Automatic repair" automatically switches it's output voltage to a safe, storage/float level that eliminates the need to worry about the damaging effects of overcharging. If/when the battery Voltage drops too far under load, output power will begin again bringing you battery back to a fully charged state. Note For automatic repair, please choose ordinary battery charging "Manual "repair This model XW-20B power charger is specially designed and manufactured for 12V/24V lead-acid, dry batteries, water batteries, lead-acid maintenance-free batteries The nominal theoretical current is: 12V-10A(max) 24V-7A(max). Please ensure the output of the charger is the same voltage as your battery. Note Only used charger "Manual" repair for in emergency situations!!! MUST be disconnected after the "Manualrepair" is fully charged, Otherwise it will damage the battery. Operation method Step 1, Examine and make sure rated voltage of battery is conforming to output voltage of charger. Step 2, Connect correctly the charger and the battery. Step 3, Examine and make sure mains supply voltage is conforming to input voltage of the charger. Step 4, Connect mains supply and the battery, watch to see if the indicator is on and the cooling fan is working when charging. Step 5, if the charger refuse to work, turn off mains supply immediately and check all the connecting cables between mains supply, the battery and the charger. Charging time reference 5-Stage Mode No-load Mode when there has no load connected with charger,the LED Screen will show voltage only,the power is about 2W; Constant Current means the battery voltage is lower than the set voltage of charger,then the charger supply constant charging current to maintenance both battery and battery charger; Constant Voltage advanced pulse width modulation (PWM) technology,control the charger's current and output voltage accurate,avoid overcharge; Floating charge when the battery is going to be charged full,the charger will stop charging,but still supply constant floating voltage and small current to battery; Trickle charge when the battery voltage and current is approaching the set voltage and current,it will turn to trickle floating charge from automatic mode,it means charge full,also can be charged with floating mode.
